TrackSense Pro Sky Option

Real-time Data with Ellab's Sky Module

The real-time data module “Sky” contains all the necessary components for collecting real-time measurements. The “Sky” module is compatible with a wide range of our TrackSense data loggers, and when combined with the “Sky Access Point” it provides a stable connection between the data logger and PC.  An external antenna is also available for more difficult transmission environments.

No data will ever be lost or corrupted due to a loss of wireless communication. If a loss of wireless communication were to occur, data is stored in the data logger and it will be transmitted once communication has been restored or the logger has been returned to the TrackSense Pro reader station.

Sensor Options

product image
Sky Access Point
View product

Key Features and Benefits


Real time data communication


Stable connection


No loss of data


Compatible with a wide range of TrackSense Pro data loggers

Sky Module 3G

Operating Temperature:

-80 °C to +140 °C

Operating Pressure:

0,001 mbar to 10 bar ABS (Other limits may apply for sensors)

Communication Range:

Up to 180 meters/600 feet (free line of sight)*

Operating Frequency:

2.4 GHz/IEEE 802.15.4 Standard


25 mm

Length of Logger with Sky Module:

66.3 mm / 91.5 mm

Intrinsically Safe (Pro, X, Basic Data Logger):

Ex II1G Ex ia IIC T3 Ga,  -60°C ≤ Tamb ≤ +105°C

Intrinsically Safe (XL Data Logger):

Ex II1G Ex ia IIC T3 Ga,  -55°C ≤ Tamb ≤ +105°C

*Range will vary depending on site and application.

The ValSuite® Software

ValSuite is the industry leading validation and calibration software, which is highly attributed to the countless reporting options, impenetrable data integrity, user-calibration options and data analysis features.

The software is used to run all Ellab hardware and can combine various measuring systems to the same study. In addition to its wide range of features, ValSuite is also FDA 21 CFR Part 11 compliant and designed in accordance with GAMP guidelines.

Features and Benefits:
FDA 21 CFR Part 11 compliant
✓ ​Safe and reliable
✓ Windows security option
✓ Compatible with Windows 10
✓ Available in several languages
✓ Suitable for all sorts of applications
✓ Multiple reporting options

And much more…

Highlighted Features

checkmark One software platform for all Ellab equipment
checkmark Combine TrackSense data loggers and the E-Val Pro wired thermocouple system in the same session
checkmark Automatic PDF report generation with clear pass/fail indication
checkmark Can run from a stand-alone PC or networked
